Compliance-Scope
Compliance-Scope is a virtual EMI/EMC laboratory that allows engineers to simulate real compliance tests directly on their designs.
Key Capabilities
Predict compliance before the lab
- Conducted Emission (CE)
- Radiated Emission (RE)
- Conducted Immunity / Susceptibility (CI / CS)
- Radiated Immunity / Susceptibility (RI / RS)
Built-in virtual lab environments
- LISNs
- Antennas
- Injection clamps
- Full test configurations
Simulation driven design intelligence
- Identify emission hotspots using near-field probes
- Separate common-mode and differential currents
- Run sensitivity and what-if analysis
Designed for real engineering workflows
- Upload standard PCB design files
- No solver expertise required
- Works within existing hardware design processes
Benefit to Customers
- Reduction in time to market ➔ Increased Revenue
- Reduction in EMC-BoM costs ➔ Higher Gross Margin
- Reduced Engineering costs ➔ Lower Operating Expenses
- Reduced Risk of Project Cancellation
Compliances Supported
Conducted Emissions
- CISPR25 Voltage Method
- CISPR25 Current Method
- MIL-STD-461G-CE101
- MIL-STD-461G-CE102
Radiated Emissions
- CISPR25
- CISPR11
- CISPR32
- MIL-STD-461G-RE102
- IEC-61967-8
Conducted Immunity
- ISO-11452-4 (BCI open/closed loop)
- MIL-STD-461G-CS114
Radiated Immunity
- ISO-11452-2
- MIL-STD-461G-RS103
- IEC-62132-8
Where Compliance- Scope Fits
EMI/EMC simulation can complement the hardware design cycle in 2 different stages
Design Stage- Prevent Problems Early
Run simulations during layout and design to identify potential EMC issues before they become expensive.
- Reduce redesign cycles
- Optimize BOM early
- Design with EMC awareness
Prototype Stage- Debug Faster
If a failure occurs in the lab, reproduce it in simulation and test fixes virtually.
- Eliminate trial-and-error
- Validate fixes before re-testing
- Reduce lab iterations
Why Compliance- Scope Wins
Generic EM solvers are not built for compliance workflows
Compliance-Scope
Built for EMC compliance
Generic EM Solvers
General-purpose, not compliance-focused
Built for Teams Responsible for EMC Performance
- Design verification engineers
- Central EMC teams
- System and hardware designers
- Product teams responsible for compliance
- Semiconductor companies
- Tier-1 suppliers
- OEMs
Real Results
EMC Simulation is Critical to Next-Gen Power Design
"There is an opportunity to differentiate in switching converters by improving thermal performance through faster switching, while relying on simulations to understand EMC performance and external component requirements. Therefore, pre-silicon EMC simulations are critical to the design process."
Early Detection of EMC Issues Reduces System Failures
“Simyog's Compliance-scope was used to analyze the Bulk Current Injection on a product design. We could clearly observe how the impedance mismatch in one of the differential lines which eventually led to common mode currents and errors in data frames sent on these differential lines. "Compliance scope allows any hardware engineer to easily reach a conclusion at an early stage.”
Pre-Silicon EMC Simulation Accelerates Time-to-Market
"SimYog's EMI/EMC simulation at the design stage significantly reduces the risk of delays & higher verification costs during the certification stage. One can benefit from cost savings in sample production, faster time-to-market, and improved product performance. SimYog plays a significant part in our product success, and we are excited about the promising roadmap"
Design-Stage Simulation Drives Superior Performance
"Compliance-Scope is essential to the design flow for switching converters. Simulation vs Measurement benchmarking on our PCB yielded results far exceeding my expectations"
Frequently Asked Questions
We answer the questions that matter most to teams
How much does the tool cost?
Please check with SimYog sales at info@simyog.com
What kind of AI features do you have in your products?
SimYog's AI assistant, "SahAI", is capable of "Helping configuring EMC tests", "Assisting with PCB imports", "Guiding simulation setup" and "Interpreting diagnostic results"
What differentiates Compliance-Scope from 3D electromagnetic solvers?
Unprecedented simulation to measurement correlation; 10x advantage in engineering man-hours to execute EMC-simulation; Please see "Why Compliance- Scope Wins" section here
Do you have simulation to measurement correlation results?
Yes, several. For publicly available correlation data please check our publications with customers available here: https://shorturl.at/wNbIV
Can simulation results be used for EMC compliance certificate?
No, atleast not as of today. Physical laboratory results from a certified laboratory is required. Simulation is aimed towards providing early EMI visibility OR for providing insights to fix a problem.
Do you offer free evaluation?
Yes, on a case-to-case basis. Please get in touch with info@simyog.com
Do you provide physical laboratory testing?
No. We provide simulation products and services using our simulation products
Do you provide simulation service?
Our primary offering is the simulation software product. On a case-to-case basis our application team can take simulation service projects.
Which EMC standards are supported?
Please check the product page on Compliance-Scope for the latest supported standards
My EMC standard is not supported. When can I expect it?
Please check with the customer success team at info@simyog.com
What is the hardware requirement to run Compliance-Scope?
Hardware requirement depends on the type of design-under-test and the EMC standard for simulation. We recommend atleast 128GB RAM and 12 cores.
What OS do your products support?
Windows 11; RHEL 8; Ubuntu 22
What are the inputs required for simulation?
PCB: ODB++ file; mCAD: 3D geometry file (.sat)
See your ROI in Action
Request a demo with your design or download detailed metrics on time and cost savings.
